| № на схеме |
Фото |
Описание |
|
|
|
2-3
|
|
HCE-HHI (HYUNDAI) Coil CAP024L-DT
|
|
|
2-2
|
|
HCE-HHI (HYUNDAI) Valve-Solenoid GS044200NC
|
|
|
2-1
|
|
HCE-HHI (HYUNDAI) Manifold 34EA-91720B
|
|
|
2
|
|
HCE-HHI (HYUNDAI) Solenoid Valve 34EA-91720
|
|
|
3-1
|
|
HCE-HHI (HYUNDAI) Connector-Orfs X540-120001
|
|
|
3
|
|
HCE-HHI (HYUNDAI) Terminal-Q/Clamp 31N4-90680
|
|
|
4
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x0 P913-047037
|
|
|
4
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x0 P913-047028
|
|
|
4
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x0 P913-047034
|
|
|
5
|
|
HCE-HHI (HYUNDAI) Pipe Assy 31N5-90540
|
|
|
5
|
|
HCE-HHI (HYUNDAI) Pipe Assy 31N5-90530
|
|
|
6
|
|
HCE-HHI (HYUNDAI) Pipe Assy 31N5-90560
|
|
|
6
|
|
HCE-HHI (HYUNDAI) Pipe Assy 31N5-90550
|
|
|
7
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x0 P910-047097
|
|
|
7
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x45 P920-047150
|
|
|
7
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x0 P910-047091
|
|
|
7
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x45 P920-047144
|
|
|
8
|
|
HCE-HHI (HYUNDAI) Hose Assy 31N4-95750
|
|
|
8
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x0 P910-047030
|
|
|
9
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x90 P930-042009
|
|
|
10
|
|
HCE-HHI (HYUNDAI) Bolt-Hex S017-160752
|
|
|
11
|
|
HCE-HHI (HYUNDAI) Washer-Spring S411-160002
|
|
|
12
|
|
HCE-HHI (HYUNDAI) Clamp-Pipe 34EA-91811
|
|
|
13
|
|
HCE-HHI (HYUNDAI) Bolt-Hex S017-100302
|
|
|
14
|
|
HCE-HHI (HYUNDAI) Tee-Run Type 31N4-22170
|
|
|
15
|
|
HCE-HHI (HYUNDAI) Connector-Orfs X500-110001
|
|
|
16
|
|
HCE-HHI (HYUNDAI) O-Ring S631-011004
|
|
|
17
|
|
HCE-HHI (HYUNDAI) Штуцер Elbow-90,Orfs X520-110001
| Производитель | HCE-HHI (HYUNDAI) |
|
|
|
18
|
|
HCE-HHI (HYUNDAI) Washer-Hardened S441-100002
|
|
|
19
|
|
HCE-HHI (HYUNDAI) Bolt-Hex S017-100502
|
|
|
20
|
|
HCE-HHI (HYUNDAI) Clamp-Band S554-054300
|
|
|
21
|
|
HCE-HHI (HYUNDAI) O-Ring,Orfs S621-011001
|
|
|
22
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x45 P920-047049
|
|
