| № на схеме |
Фото |
Описание |
|
|
|
K1-1
|
|
HCE-HHI (HYUNDAI) Seal Kit ZTAV-00035
|
|
|
1
|
|
HCE-HHI (HYUNDAI) Power Train Pump 31N5-30020
|
|
|
7
|
|
HCE-HHI (HYUNDAI) Accumulator 31EC-02190
|
|
|
8
|
|
HCE-HHI (HYUNDAI) Switch-Pressure 34EA-30160
|
|
|
9
|
|
HCE-HHI (HYUNDAI) Switch-Pressure 31L7-40030
|
|
|
15
|
|
HCE-HHI (HYUNDAI) Connector 31N6-30120
|
|
|
15
|
|
HCE-HHI (HYUNDAI) Connector-Long 31EM-30140
|
|
|
17
|
|
HCE-HHI (HYUNDAI) Connector 31EE-30061
|
|
|
20
|
|
HCE-HHI (HYUNDAI) Connector-Orfs X500-110001
|
|
|
20
|
|
HCE-HHI (HYUNDAI) Connector P010-110002
|
|
|
21
|
|
HCE-HHI (HYUNDAI) Connector-Orfs X500-110002
|
|
|
21
|
|
HCE-HHI (HYUNDAI) Connector P010-110003
|
|
|
23
|
|
HCE-HHI (HYUNDAI) Connector 31N5-30050
|
|
|
23
|
|
HCE-HHI (HYUNDAI) Connector P010-310005
|
|
|
25
|
|
HCE-HHI (HYUNDAI) Connector-Orfs X500-310003
|
|
|
28
|
|
HCE-HHI (HYUNDAI) Elbow-90,Orfs X520-110002
|
|
|
28
|
|
HCE-HHI (HYUNDAI) Elbow-90 P020-110002
|
|
|
29
|
|
HCE-HHI (HYUNDAI) Elbow-90,Orfs X520-110012
|
|
|
29
|
|
HCE-HHI (HYUNDAI) Elbow-90 P020-110012
|
|
|
32
|
|
HCE-HHI (HYUNDAI) Elbow-90,Orfs,Long 31N8-40310
|
|
|
33
|
|
HCE-HHI (HYUNDAI) Tee 31N4-22110
|
|
|
34
|
|
HCE-HHI (HYUNDAI) Flange-Split P173-080101
|
|
|
35
|
|
HCE-HHI (HYUNDAI) Flange 31N4-30220
|
|
|
36
|
|
HCE-HHI (HYUNDAI) Plug-Hex P220-110102
|
|
|
37
|
|
HCE-HHI (HYUNDAI) Plug-Hex P220-110103
|
|
|
39
|
|
HCE-HHI (HYUNDAI) Washer-Copper P392-120000
|
|
|
40
|
|
HCE-HHI (HYUNDAI) Washer-Copper P392-180000
|
|
|
43
|
|
HCE-HHI (HYUNDAI) Bolt-W/Washer S035-083026
|
|
|
44
|
|
HCE-HHI (HYUNDAI) Bolt-W/Washer S037-122522
|
|
|
45
|
|
HCE-HHI (HYUNDAI) Bolt-Socket S109-080256
|
|
|
46
|
|
HCE-HHI (HYUNDAI) Bolt-Socket S109-100256
|
|
|
47
|
|
HCE-HHI (HYUNDAI) Bolt-Socket S109-060756
|
|
|
51
|
|
HCE-HHI (HYUNDAI) Clamp-Band S551-050203
|
|
|
53
|
|
HCE-HHI (HYUNDAI) O-Ring S611-016001
|
|
|
54
|
|
HCE-HHI (HYUNDAI) O-Ring S621-014001
|
|
|
55
|
|
HCE-HHI (HYUNDAI) O-Ring S621-018001
|
|
|
56
|
|
HCE-HHI (HYUNDAI) O-Ring S631-011004
|
|
|
57
|
|
HCE-HHI (HYUNDAI) O-Ring S631-014004
|
|
|
58
|
|
HCE-HHI (HYUNDAI) O-Ring S631-018004
|
|
|
59
|
|
HCE-HHI (HYUNDAI) O-Ring Y171-015004
|
|
|
60
|
|
HCE-HHI (HYUNDAI) O-Ring S631-025004
|
|
|
61
|
|
HCE-HHI (HYUNDAI) Hose Assy 31N4-30211
|
|
|
62
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs,Flg 0x45 P950-084363
|
|
|
63
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs,Flg 0x45 P950-084382
|
|
|
63
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs,Flg 0x45 P950-084385
|
|
|
64
|
|
HCE-HHI (HYUNDAI) O-Ring S621-021001
|
|
|
65
|
|
HCE-HHI (HYUNDAI) Connector-Long,Orfs X511-106523
|
|
|
65
|
|
HCE-HHI (HYUNDAI) Connector-Long P101-106063
|
|
|
67
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x90 P930-066036
|
|
|
67
|
|
HCE-HHI (HYUNDAI) Hose Assy-Thd 0x90 P620-066040
|
|
|
71
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x90 P930-082049
|
|
|
72
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x90 X420-042041
|
|
|
72
|
|
HCE-HHI (HYUNDAI) Hose Assy-Syn 0x90 P860-042039
|
|
|
77
|
|
HCE-HHI (HYUNDAI) Hose Assy-Synf,Orfs X400-062053
|
|
|
77
|
|
HCE-HHI (HYUNDAI) Hose Assy-Syn Thd P840-062051
|
|
|
80
|
|
HCE-HHI (HYUNDAI) O-Ring,Orfs S621-011001
|
|
|
81
|
|
HCE-HHI (HYUNDAI) O-Ring S621-012001
|
|
|
82
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs 0x90 P930-087008
|
|
|
83
|
|
HCE-HHI (HYUNDAI) Tee-R/Type,Swivel,Orfs X840-535353
|
|
|
84
|
|
HCE-HHI (HYUNDAI) Plug-Orfs X700-100104
|
|
|
85
|
|
HCE-HHI (HYUNDAI) Connector-Test 31N6-39130
|
|
