| № на схеме |
Фото |
Описание |
|
|
|
1
|
|
HCE-HHI (HYUNDAI) Pipe Assy-Suction 31N5-11102
|
|
|
2
|
|
HCE-HHI (HYUNDAI) Bolt-Socket S109-120456
|
|
|
2-5
|
|
HCE-HHI (HYUNDAI) O-Ring S631-044004
|
|
|
2-4
|
|
HCE-HHI (HYUNDAI) Elbow-90,Orfs X520-110022
|
|
|
2-4
|
|
HCE-HHI (HYUNDAI) Connector-Orfs X500-110023
|
|
|
2-3
|
|
HCE-HHI (HYUNDAI) Pipe Assy 32N5-11120
|
|
|
2-3
|
|
HCE-HHI (HYUNDAI) Pipe Assy-Return 31N5-11122
|
|
|
2-3
|
|
HCE-HHI (HYUNDAI) Pipe Assy-Return 31N5-11121
|
|
|
2-2
|
|
HCE-HHI (HYUNDAI) Check Valve 31N5-11150
|
|
|
2-1
|
|
HCE-HHI (HYUNDAI) Valve-Check 31E9-0143
|
|
|
2
|
|
HCE-HHI (HYUNDAI) Pipe Sub Assy 31N5-11400
|
|
|
2
|
|
HCE-HHI (HYUNDAI) Pipe Sub Assy 31N5-1112-SUB
|
|
|
3
|
|
HCE-HHI (HYUNDAI) Pipe Assy 32N5-11130
|
|
|
3
|
|
HCE-HHI (HYUNDAI) Pipe Assy-Return 31N5-11133
|
|
|
3
|
|
HCE-HHI (HYUNDAI) Pipe Assy-Return 31N5-11132
|
|
|
4
|
|
HCE-HHI (HYUNDAI) Pipe Wa 32N5-11160
|
|
|
4
|
|
HCE-HHI (HYUNDAI) Pipe Assy-Return 31N5-11160
|
|
|
5
|
|
HCE-HHI (HYUNDAI) Pipe Wa 32N5-12280
|
|
|
5
|
|
HCE-HHI (HYUNDAI) Pipe Assy 31N4-12291
|
|
|
6
|
|
HCE-HHI (HYUNDAI) Bracket-R/Pipe 31N4-14250
|
|
|
6
|
|
HCE-HHI (HYUNDAI) Bracket-Return 31N5-10151
|
|
|
8
|
|
HCE-HHI (HYUNDAI) Hose Assy 31N5-11210
|
|
|
8
|
|
HCE-HHI (HYUNDAI) Hose Assy-Orfs,Flg 0x90 P993-127421
|
|
|
9
|
|
HCE-HHI (HYUNDAI) Hose Assy-Return 31N5-11181FL
|
|
|
9
|
|
HCE-HHI (HYUNDAI) Hose Assy-Return 31N5-11180FL
|
|
|
10
|
|
HCE-HHI (HYUNDAI) Flange-Hyd,Split P174-120102
|
|
|
11
|
|
HCE-HHI (HYUNDAI) Clamp-Pipe 31EG-12190
|
|
|
13
|
|
HCE-HHI (HYUNDAI) Connector-Orfs X500-110004
|
|
|
14
|
|
HCE-HHI (HYUNDAI) Hose-Rubber P760-063019
|
|
|
15
|
|
HCE-HHI (HYUNDAI) Hose-Rubber 31N4-15370
|
|
|
15
|
|
HCE-HHI (HYUNDAI) Hose-Rubber P760-073019
|
|
|
15
|
|
HCE-HHI (HYUNDAI) Hose-Rubber P760-073016
|
|
|
16
|
|
HCE-HHI (HYUNDAI) Hose-Rubber P760-103025
|
|
|
17
|
|
HCE-HHI (HYUNDAI) Clamp-Hose,Wire Type S572-570006
|
|
|
18
|
|
HCE-HHI (HYUNDAI) Clamp-Hose,Wire Type S572-640006
|
|
|
18
|
|
HCE-HHI (HYUNDAI) Clamp-Hose,Wire Type S572-650006
|
|
|
19
|
|
HCE-HHI (HYUNDAI) Clamp-Hose,Wire Type S572-950006
|
|
|
20
|
|
HCE-HHI (HYUNDAI) Bolt-Hex S017-120706
|
|
|
20
|
|
HCE-HHI (HYUNDAI) Bolt-Hex S017-120806
|
|
|
21
|
|
HCE-HHI (HYUNDAI) Bolt-W/Washer S037-123026
|
|
|
22
|
|
HCE-HHI (HYUNDAI) Bolt-Socket S109-100306
|
|
|
23
|
|
HCE-HHI (HYUNDAI) Bolt-Socket S109-100356
|
|
|
24
|
|
HCE-HHI (HYUNDAI) Bolt-Socket S109-120306
|
|
|
25
|
|
HCE-HHI (HYUNDAI) Nut-Hex S205-121006
|
|
|
26
|
|
HCE-HHI (HYUNDAI) Washer-Plain S403-12200B
|
|
|
27
|
|
HCE-HHI (HYUNDAI) Washer-Spring S411-120006
|
|
|
28
|
|
HCE-HHI (HYUNDAI) O-Ring S631-024004
|
|
|
29
|
|
HCE-HHI (HYUNDAI) O-Ring S631-071001
|
|
|
30
|
|
HCE-HHI (HYUNDAI) O-Ring Y171-027004
|
|
|
31
|
|
HCE-HHI (HYUNDAI) O-Ring Y172-003004
|
|
|
32
|
|
HCE-HHI (HYUNDAI) O-Ring Y171-019004
|
|
|
33
|
|
HCE-HHI (HYUNDAI) O-Ring S621-018001
|
|
|
34
|
|
HCE-HHI (HYUNDAI) O-Ring S621-025001
|
|
